Dragino LDDS12 LiDAR ToF Distance LoRaWAN Sensor
- Measures distance with high accuracy and speed using Time-of-Flight (ToF) technology
- Measurement range of up to 12 meters with an accuracy of up to ±3 cm.
- Real-time data visualization for easy monitoring of operations
- User-friendly interface and simple setup process for easy installation and configuration
- Low power consumption with a single 3.6V battery providing up to 10 years of continuous operation.
- Sends alerts and notifications when specific thresholds are reached

Overview
The Dragino LLDS12 is a LoRaWAN LiDAR ToF (Time of Flight) Distance Sensor for an Internet of Things solution. It measures the distance to an object as close as 10 centimeters (±5 cm up to 6 m) and as far as 12 meters (±1% starting at 6 m)! The LiDAR probe uses laser induction technology for distance measurement.
The LLDS12 can be applied to scenarios such as horizontal distance measurement, parking management system, object proximity and presence detection, intelligent trash can management system, robot obstacle avoidance, automatic control, sewer, etc.
It detects the distance between the measured object and the sensor and uploads the value via wireless to a LoRaWAN IoT Server.
The LoRa wireless technology used in LLDS12 allows devices to send data and reach extremely long ranges at low data rates. It provides ultra-long-range spread spectrum communication and high interference immunity, minimizing current consumption.
LLDS12 is powered by an 8500 mAh Li/SOCl₂ battery, designed for long-term use for up to 5 years.
Applications
- Horizontal distance measurement
- Parking management system
- Intelligent trash can management system
- Liquid level measurement
- Object proximity and presence detection
- Robot obstacle avoidance

Small Applications
Advanced sensor technology provides real-time monitoring of container levels, enabling optimization of collection routes and reducing unnecessary pickups. Long-range wireless connectivity enables remote management of waste management systems, improving efficiency and reducing environmental impact.
Large Applications
Our sensors can monitor waste levels in large dumpsters, providing data for streaming the collection process and improving efficiency. The durable design of the sensors makes them suitable for harsh environments. By leveraging this technology, companies can improve sustainability and reduce operational costs.
